findmall 4 Inch Lock Down Vise Accuracy Milling Vise 4 Inch Jaw Width Drill Press Vise Milling Drilling Machine Bench Clamp Clamping Vice(4")

findmall 4 Inch Lock Down Vise Accuracy Milling Vise 4 Inch Jaw Width Drill Press Vise Milling Drilling Machine Bench Clamp Clamping Vice(4")

Regular price $109.57 USD
Regular price $0.00 USD Sale price $109.57 USD
Sale Sold out
Shipping calculated at checkout.

In stock

Adaptive Image

Specification:

Milling Vise 4 Inch

Jaw width: 3.93 inch (100 mm)

Jaw opening: 3.93 inch (100 mm)

Bench clamp vise height: 3.86 inch (100 mm)

Jaw height: 1.3 inch (32 mm)

Accurate to 0.002 per 4 on squareness and 0.006 per 4 on parallelism without base

Vise Key: 11.11mm table slot width, 14.00mm base width

Product features

Each pound of force in horizontal induces 1/2 lb of downward force, eliminating jaw tilt

This Vise is so designed that the horizontal force generated by tightening the handle pushes the semi-sphere within the movable jaw and thus thrusts the movable jaw downward

The workplace does not move up, even if it is held at the top of the jaw plates

Highest clamping power. It's very accurate and durable

Sliding surface of the vise bed is flame hardened and ground

Vise bed is made from grey cast iron and the maximum tensile strength of the vise bed is 28,000 PSI

With anti-jaw lifting mechanism. K type angle lock nut is made from the highest quality ductile Iron, firm and durable

Acme screws and easy to read 0-360 deg scales

Screws from the top through the jaw make the vise more stable and durable. Taiwan new type

The installation size of Soft Jaw is the same as Kurt. 4" Aluminum Soft Jaws which are made in USA can be mounted into this vise

Four setting positions of the jaw plates are available, widening the jaw plates opening
